Fingerprint Optical Barrier Turnstiles Access Control System Self Reset Function

Place of Origin Shenzhen, China
Brand Name Turboo
Certification CE, ISO9001
Model Number K249
Minimum Order Quantity 1 PC
Price Negotiable
Packaging Details Wooden case package
Delivery Time 7-15 working days
Payment Terms L/C, T/T
Supply Ability 1000 units per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Size 1400X280X980 Material 304/316 Stainless Steel
Input 100~240 Power 220V 50Hz
High Light

glass swing gate

,

gate card reader

,

Fingerprint Optical Barrier Turnstiles

Leave a Message
Product Description

Fingerprint flap barrier gate turnstile with walk through gate for access control







Features and Benefits



1. 1.5mm 304 Stainless steel , self designed, good appearance, toughened glass in reader window to prevent hurt, LCD on top(option) to display user information.

2. 8 pairs of infrared sensors to prevent hurt when with baggage or children, can add more for more accurately control and judgment.

3. Infrared sensors and firmware to prevent tagging after and alarm

4. High light huge LED on top and besides shows the direction and its status, Red to show prohibiting passing and Green to show allowing passing

5. NO(Normally Open)/NC(Normally Closed) mode optional to relax the following speed

6. Can adjust open/close speed of wing according to the following speed

7. Self reset function. When user doesn’t passing in set time, the system will automatically cancel this passing, the time can be set in software

8. Supply many Standard interface like RJ45 /RS485/232 to connect to EM ID, Mifare 1 IC, CPU CARD,TI, Magnetic, Barcode, fingerprint, hand, face readers, card insert/swallow machine, LED/LCD display, strong compatibility, easy to system integration.

9. Using ARM as CUP chip, stable running, better performance,and more interface to connect input and output signal, Using TCP/IP Protocol, realtime data uploading or manually data upload, easy to data analysis, no data losing when big data or data cash

10. Reading card with memory or without memory optional.



Model
K249
Size
1400x280x980mm
Material
1.2mm thickness SUS304
Pass Width
550mm
Passage direction
Single directional/Bi-directional
Pass rate
30-35 persons/minute
Operating time
0.2 seconds
Power input
AC100-240V,50/60HZ
Working voltage
24V
Working humidity
30%~95%
Working temperature
-40℃~+70℃
Working environment
Indoor
Communication interface
RS485, Dry contact
Mechanism
Brushed Motor+Germany Belt
Infrared sensor
5 pairs
MCBF
5,000,000 Cycles
Application
Station, Sea ports, GYM, Shool, etc
