304 Stainless Steel Security Swing Gate D343

Name: 304 Stainless Steel Security Swing Gate D343
Brand: Turboo Automation Co., Ltd
SKU: D343
Price: Negotiable USD
Availability: InStock

Brand Name:	Turboo
Model Number:	D343
MOQ:	1 PC
Price:	Negotiable
Delivery Time:	7-15 working days
Payment Terms:	T/T, L/C

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Certification:

CE, ISO9001

Packaging Details:

Wooden case package

Supply Ability:

1000 units per month

Highlight:

drop arm turnstiles

security entrance systems

304 SS Security Swing Gate

Product Description

Security passage smart bike pass turnstile 304 stainless steel swing barrier gate

Product Description

Technical Data	Unit	D343
Passage width	mm	600-900
Throughput rate	p/m	35
Power supply	V(ac)	24V 150W
Operational voltage	V(dc)	24
Mechanism	FD	Brushless integrated swing gate
Frequency	hz	50-60
Prectection level	ip	>44
Working temperature	degree	-25 to +70
Dimension excluding bars	mm	1200x280x980
Net weight including bars	Kg	single movement 35kg/ dual 42kg

Optional devices	1.Fingerprint reader	2.Face recognition
	3.Card collector	4.Card reader
	5.2D scanner	6.Palmprint reader

Functions

Being able to program running status by the small keyboard in the main board

Preventing pedestrians from being nipped and from hurt

Light and sound alarm funtion including the illegal in and the tail

Arms are automatically locked untill opening signal is received.
Arms synchronization (adjustable)
Automatically reset function: It will automatically lock if the pedestrian hasn't pass through the channel in the pre-set time after the opening. The passing time is adjustable

Automatically open the gate when power off and automatically close when power on
Several card readers are attachable, and relay singals can be received.
One direction or bi-direction are optional

It can be directly controlled and managed by remote control.

304 Stainless Steel Security Swing Gate D343
