| Brand Name: | Turboo |
| Model Number: | Y248 |
| MOQ: | 1 PC |
| Price: | Negotiable |
| Delivery Time: | 7-15 working days |
| Payment Terms: | T/T, L/C |
| Technical Data | Unit | Y248 |
| Passage width | mm | <550 |
| Throughput rate | p/m | 35 |
| Power supply | V(ac) | 100-240 |
| Operational voltage | V(dc) | 24 |
| Max power consumption | w | 35 |
| Frequency | hz | 50-60 |
| prectection level | ip | >44 |
| Working temperature | degree | -25 to +70 |
| Dimension excluding bars | mm | 1200X280X980 |
| Net weight including bars | Kg | 48 |
Features and Benefits
1. Alarm buzzer detection for unauthorized usage
Alarm buzzer function will be triggered when the user is passing through without authorization,tail gating or incorrect directon.
2. Elegant design
Slim from factor,premium stainless steel and glass panel material with elegant arc design effectively help creat a welcoming and elegant prestigious atmospher at building entrance to impressive your visitor.
3. Double safety
Door will automatically reverse once safety IR detected obstacle or when a small force is detected blocking its motion.This dual detection feature is to prevent injury caused by door hitting people.
4. Easy integration
A push button or access control reader can be used to trigger the swing barrier to open via simple dry contact signal.After delay timer elasped,swing barrier will automatically close back by itself.
5. Minimum maintainance
User brushless DC motor eliminate the need of changing carbon brush thus reducing maintenance work.Key internal parts are treated with anti-rust and anti-septic to ensure long term reliability.
6. Emergency recovery
During power failure,swing barrier will automatically open for free pass through.This will fast escape in the event of emergency.When the power resume,swing barrier will automatically close back.
