ADA Compliant Automatic Swing Barrier Gate Double Anti - Clipping Function

Place of Origin Shenzhen, China
Brand Name Turboo
Certification CE, ISO9001
Model Number H306
Minimum Order Quantity 1 PC
Price Negotiable
Packaging Details Wooden case package
Delivery Time 7-15 working days
Payment Terms T/T, L/C
Supply Ability 2000 units per month
Product Details
Material 304 Stainless Steel Or 316 Stainless Steel Size 1400X185X1020
Passage Width ≤900mm Working Temperature -25~+70℃
Net Weight Including Bars 95kg Thickness Full 1.5mm
Reliability Of The Core 3 Million No Fault Driving Voltage 24 V
High Light

waist height turnstile

,

security entrance systems

Leave a Message
Product Description

ADA Compliant Automatic Swing Turnstile Stainless Steel Semi-automatic



Product Discription
The material is standard 304 stainless steel, during the casing whithin a professional guide tank. and during the casing within a professional guide tank. Can be installed in indoor, outdoor with shed, applicable to restrict the passing rate of the place, has the count, attendance, current limiting funtion. The enterclose are more wider than others.Have a higher traffic capacity, can make motorcycle, bicycle and other small vehicles through, also can be used as a barrier-free access.


OPERATING MODES
• Single passage in the set direction
• Bi-directional single passage
• Free passage in the set direction
• Always free or locked


MATERIALS
• Housing:Made in stainless steel AISI 304 o AISI316.
• Barrier swings-Acrylic, PC, stainless steel frame.


FEATURES AND BENEFITS

  • Running stable, little noise and no mechanical impact
  • Various working means can be set in the control panel menu, namely: Bi-direction card reading passing, or one direction card reading passing and another passing limits, or one direction card reading passing and another free passing, etc.
  • It is with standard electrical interface to connect various kinds of readers and writers for easy integration and also computer far control and management can be realized by computer.
  • Card reading memory or card reading without memory function can be set in the control panel menu according to your request.
  • Uncompleted wheel turning system is adopted for locking the turnstile in zero, and unlocking will be more reliable and accurate.
  • Double anti-clipping function, photocell antic lipping and mechanical anti-clipping
  • Auto re-set function, if no passing during identified card-reading time, the system will reset automatically the passengers are prohibited to pass until their second identified reading
  • The barrier can be set to delay closing in 1-60s after a valid card-reading
Technical DataUnitH306
Passage widthmm<=900
Throughput ratep/m35
Power supplyV(ac)100-240
Operational voltageV(dc)24
Max power consumptionw35
Frequencyhz50-60
prectection levelip44
Working temperaturedegree-25 to +70
Dimension excluding barsmm1400X185X1020
Net weight including barsKg95
