Brand Name: | Turboo |
Model Number: | A221B |
MOQ: | 1 PC |
Price: | Negotiable |
Delivery Time: | 7-15 working days |
Payment Terms: | T/T, L/C |
1. 90% of production processes are developed by ourselves so we can control the costs and provide the competitive price correspondingly.
2. More than 20,000 sq.m area plant, abundant stock, short delivery time;
3. Top 3 suppliers of raw material and spare aprts, like Baoxin and Japan Imported Stainless steel, Germany belts and motors, MEANWELL power supply etc.
4. Long Lifecycles: Brushless Servo Motors need least maintenance and provides more than 5,000,000 cycles MCBF.
5. High Intergrated: Compatible with most access control systems and credentials like RFID Cards,Barcodes,QR codes, Fingerprints, Face recognition,etc.
6. Easy Operation: Our own developed mainboard for easy operation and maintenance.
7. Wide Applications: widely applied for Banks,offices,Library,University and other high end places.
8. Timely technical support and after sales.
Features and Benefits
Compatible with RF card readers, bar code readers, biometric readers, push button...
Equipped with infrared photocell, alarm while unauthorized entry or tailgating attempts, together with anti-strike function to protect pedestrian.
Expanded to automatic identification system, access control system, Traffic control, attendance check and fare collection system etc.
Automatically reset : lock automatically while the pedestrian not pass the lane in the pre-set time after the flap opened. The passing time is adjustable.
Equipped with international interface, can be easily integrated with other R/W device and managed through remote supervision computer
Communication
• Dry contact relay with 12 volt or 24 volt pulse
• Rs485, or Tcp-lp communication with computer
Technical Data | Unit | A221B |
Passage width | mm | <550 |
Throughput rate | p/m | 35 |
Power supply | V(ac) | 100-240 |
Operational voltage | V(dc) | 24 |
Max power consumption | w | 35 |
Frequency | hz | 50-60 |
prectection level | ip | >44 |
Working temperature | degree | -25 to +70 |
Dimension excluding bars | mm | 1410X300X990 |
Net weight including bars | Kg | 87 |
![]() |
