LED Lamp Indication Flap Barrier Turnstile Access Control Security Systems

Place of Origin Shenzhen, China
Brand Name Turboo
Certification CE, ISO9001
Model Number A221B
Minimum Order Quantity 1 PC
Price Negotiable
Packaging Details Wooden case package
Delivery Time 7-15 working days
Payment Terms T/T, L/C
Supply Ability 1000 units per month
Product Details
Material 304 Stainless Steel Or 316 Stainless Steel Thickness Full 1.2mm Or Full 1.5mm
Size 1400X300X1005 Passage Width ≤550mm
Testing 3 Million No Fault Input 220V,50HZ Or 110 V ,50HZ
Driving Voltage 24 V Environment -25~+70
High Light

drop arm turnstiles

,

security access gates

,

LED Indication Flap Barrier Turnstile

Leave a Message
Product Description

Stainless Steel Optical Pedestrian Flap Barrier Turnstile Gate Access Control







Product Description



Wing turnstile, one kind of pedestrian turnstiles, is also known as blocking turnstile and butterfly turnstile and is the upgraded version turnstile when compared with ordinary tripod turnstile and swing turnstile as its appearance is more luxurious. The product is made of stainless steel casing, electronic control for machine core, telescopic arm, infrared, LED lamps and other components. The wing turnstile is characterized by a fixed channel width and generally used for the passage of people and small pieces of luggage rather than bicycle wheel chair (except for those of special styles). It is provided with fire-fighting interfaces and infrared/mechanical multiple anti-pinch functions.



Features and Benefits

1. Passage direction: the free setting of uni-direction or bi-direction to control access, and uni-directional free passage, bi-directional free passage or uni-directional card swiping passage or bi-directional card swiping passage are allowed.

2. Automatic reset:if the pedestrian fails to pass through within the system preset period after swiping the card and opening the turnstile, the system will cancel the passage permissions (adjustable resetting time) and close the turnstile automatically.

3. Memory function:continuous swiping card allows multiple persons to pass, and this is suitable for special occasions.

4. Equipment compatibility:standard input/output interfaces are provided for the connection with various identification system devices.

5. Remote control:it enables remote control and management directly by supervisory computer via equipment serial ports, and is able to detect equipment running state and modify operating parameters in real time.

6. Passage indication:it is equipped with channel normally on LED indicator and real-time passage LED lamp indication.

7. Illegal passage: it implements the standard passage mode of one card for one person to prevent intrusion and trailing, and the turnstile will close and give alarms in case of any illegal passages.

8. Passage under power failure: in case of utility failure, the equipment will automatically open the turnstile to prevent channel blockage and will automatically reset after energizing.



Communication

• Dry contact relay with 12 volt or 24 volt pulse

• Rs485, or Tcp-lp communication with computer


Technical Data Unit A221B
Passage width mm <550
Throughput rate p/m 35
Power supply V(ac) 100-240
Operational voltage V(dc) 24
Max power consumption w 35
Frequency hz 50-60
prectection level ip >44
Working temperature degree -25 to +70
Dimension excluding bars mm 1410X300X1005
Net weight including bars Kg 87
