| Brand Name: | Turboo |
| Model Number: | EL128 |
| MOQ: | 1 unit |
| Price: | Negotiable |
| Delivery Time: | 7-15 working days |
| Payment Terms: | T/T, L/C |
Features and Benefits
1. Equipment compatibility: standard input/output interfaces for the equipment are provided for the connection with various identification system devices.
2. Remote control: it enables remote control and management directly by supervisory computer via equipment serial ports, and is able to detect equipment running state and modify operating parameters in real time.
3. Passage indication: it is equipped with channel normally on LED indicator and real-time passage LED lamp indication.
4. Fire-safety linkage: the turnstile will open automatically and enter the emergency mode when the equipment receives the fire-safety signal in the case of constant power supply.
5. Anti-pass-back: the machine can only move forward by default so as to prevent illegal pass-back after the turnstile rod rotating 60°.
6. Passage under power failure: the equipment will automatically drop its rod to ensure smooth operation under the city power failure; after the recovery of power supply, the channel keep closed
Communication
• Dry contact relay with 12 volt or 24 volt pulse
• Rs485, or Tcp-lp communication with computer
| Technical Data | Unit | EL128 |
| Passage width | mm | <550 |
| Throughput rate | p/m | 35 |
| Power supply | V(ac) | 100-240 |
| Operational voltage | V(dc) | 24 |
| Max power consumption | w | 30 |
| Frequency | hz | 50-60 |
| prectection level | ip | >44 |
| Working temperature | degree | -25 to +70 |
| Dimension excluding bars | mm | 470X280X960 |
| Net weight including bars | Kg | 33 |
Video
Video
Video
Video
Video
Video
Video
|
| Brand Name: | Turboo |
| Model Number: | EL128 |
| MOQ: | 1 unit |
| Price: | Negotiable |
| Packaging Details: | Wooden case package |
| Payment Terms: | T/T, L/C |
Features and Benefits
1. Equipment compatibility: standard input/output interfaces for the equipment are provided for the connection with various identification system devices.
2. Remote control: it enables remote control and management directly by supervisory computer via equipment serial ports, and is able to detect equipment running state and modify operating parameters in real time.
3. Passage indication: it is equipped with channel normally on LED indicator and real-time passage LED lamp indication.
4. Fire-safety linkage: the turnstile will open automatically and enter the emergency mode when the equipment receives the fire-safety signal in the case of constant power supply.
5. Anti-pass-back: the machine can only move forward by default so as to prevent illegal pass-back after the turnstile rod rotating 60°.
6. Passage under power failure: the equipment will automatically drop its rod to ensure smooth operation under the city power failure; after the recovery of power supply, the channel keep closed
Communication
• Dry contact relay with 12 volt or 24 volt pulse
• Rs485, or Tcp-lp communication with computer
| Technical Data | Unit | EL128 |
| Passage width | mm | <550 |
| Throughput rate | p/m | 35 |
| Power supply | V(ac) | 100-240 |
| Operational voltage | V(dc) | 24 |
| Max power consumption | w | 30 |
| Frequency | hz | 50-60 |
| prectection level | ip | >44 |
| Working temperature | degree | -25 to +70 |
| Dimension excluding bars | mm | 470X280X960 |
| Net weight including bars | Kg | 33 |
