| Brand Name: | Turboo |
| Model Number: | Y248 |
| MOQ: | 1 PC |
| Price: | Negotiation |
| Delivery Time: | 7 days |
| Payment Terms: | L/C, T/T, |
Features and Benefits
1. Use IC cards, ID cards, Bar code or magnetic cards as automatic identification system and achieve access, attendance fees or function
2. A direction indicator, showed that pedestrian access to the current status of, and guide pedestrians correct and smooth passage
3. Display has been in use for statistics and numbers
4. With voice and strobe light alerts
5. A combination of infrared sensors and police ant illegal entry into pedestrian access, the protection of pedestrians smooth and the prevention of the channel following
6. Double anti-clipping function, photocell antic lipping and mechanical anti-clipping
7. Auto re-set function, if no passing during identified card-reading time, the system will reset automatically the passengers are prohibited to pass until their second identified reading
8. The barrier can be set to delay closing in 1-60s after a valid card-reading
OPERATING MODES
1. Single passage in the set direction
2. Bi-directional single passage
3. Free passage in the set direction
4. Always free or locked
MATERIALS
1.. Housing and arm: Made in stainless steel AISI 304 o AISI316.
2. PC flap and moulding machine core
| Technical Data | Y248 |
| Dimension | 1200x280x980mm |
| Unlock time | 0.2s |
| Passage width | ≤550mm |
| Throughput rate | 35p/m |
| Power supply | 100~240v |
| Operational voltage | 24v |
| Max power consumption | 35w |
| Frequency | 50~60hz |
| Prectection level | 44ip |
| Working temperature | -25~70 °C |
| Electro-magnetic drive | DC |
| Net weight | 70kg |
| Input | 12v dry contact |
