| Brand Name: | Turboo |
| Model Number: | E242 |
| MOQ: | 1 PC |
| Price: | Negotiable |
| Delivery Time: | 7-15 working days |
| Payment Terms: | T/T, L/C |
Features and Benefits
1. Problem-self-checking function.
2. Arm Turning: Bi-direction
3. When power off, arm open automatically and power on again, arm will be held automatically.
4. When valid card read and passenger passed, arm can be delayed to close from 1-60s which can be set in.
5. Auto-reposition function: After card read, passenger doesn’t pass within regulated time, turnstile
will cancel order automatically. And the regulated time can be set by managers.
6. Anti-rush function: if there is no open single, arm will be holding tightly.
7. Stable running with little noise.
Communication
• Dry contact relay with 12 volt or 24 volt pulse
• Rs485, or Tcp-lp communication with computer
| Technical Data | Unit | E242 |
| Passage width | mm | <550 |
| Throughput rate | p/m | 35 |
| Power supply | V(ac) | 100-240 |
| Operational voltage | V(dc) | 24 |
| Max power consumption | w | 35 |
| Frequency | hz | 50-60 |
| prectection level | ip | >44 |
| Working temperature | degree | -25 to +70 |
| Dimension excluding bars | mm | 1200X280X980 |
| Net weight including bars | Kg | 50 |
